Description
The UK Cylinders Elite SG+ ESAMB5020 is an all-in-one domestic hot water (DHW) and buffer cylinder engineered specifically for modern air-to-water heat pump systems. By integrating a 200-litre unvented hot water cylinder and an integrated 50-litre buffer vessel into a single vertical footprint, it optimises plant room space and slashes on-site installation time.
Manufactured in the UK from premium-grade Duplex stainless steel, the unit delivers exceptional corrosion resistance, superior thermal stratification, and long-term reliability. The integrated buffer ensures vital hydraulic separation, protects the heat pump compressor lifespan by preventing short cycling, and maintains smooth defrost cycles without compromising home comfort.
Key Features & Benefits
-
All-in-One Space-Saving Design: Combines a 200L unvented hot water cylinder with a 50L heating buffer tank in a single compact enclosure.
-
Factory Pre-Plumbed & Pre-Wired: Minimises labour costs and installation errors with a factory-fitted circulating pump, wiring centres, and zone controls.
-
High-Gain Heat Exchange Coil: Features a large surface area, full-bore 28 mm primary coil engineered for low-temperature heat pump operation, ensuring rapid reheat times and maximum heat transfer efficiency.
-
Exceptional Thermal Insulation: Encased in 50 mm CFC/HCFC-free polyurethane foam insulation to minimise standing heat loss and lower domestic energy bills.
-
Built-in Immersion Back-Up: Includes a factory-fitted 3 kW Incoloy immersion heater for emergency heating and automated anti-legionella pasteurisation cycles.
-
Robust Duplex Stainless Steel: High strength-to-weight ratio with a 57 kg dry weight for easier handling and positioning on site.
-
Complete Compliance: Fully compliant with UK Building Regulations Part G3.
